Brand Name : SCXK
Model Number : P8
Certification : CE/ROHS/FCC/ISO/UL
Place of Origin : China
MOQ : 1sqm
Price : negotiation
Payment Terms : T/T
Delivery Time : 7working days
Packaging Details : flight case, wooden case
Supply Ability : 3000 sqm per month
Pixel Density : 15625
Brightness : 7000
Control System : LSN
LED Shape & Size : 3mm smd3535
Module Size : 256*128
Driver mode : 1/4 scan
Operation Power : 220V 60HZ
Display Color : 1.07 billion
P8 outdoor led display SMD
P8 Outdoor Led Display Product Detail
1.Front or rear maintenance option
Front or rear maintenance option, realizing module, power supply and receiving card front or rear maintenance, saving your maintenance cost.
2.Energy Saving≥50%, Environment Protection
Adopt top high brightness with low power consumption LED lamp,energy saving≥30%, if adopt 28 kinds of main patent technique, entire energy saving ≥50%, environment protection.
Pioneer in outdoor mature HD LED Display, all advanced specifications 2 years earlier than others, successful cases around the world.
3.Firm, Flat and Backup Solution
Dark black surface,firm and flat, anti-UV module parts, which gurantees screen in firm shape.
Power supplier and control system, backup solution is available to gurantee.
Camera optional, Lan cable, 3G, WIFI, Multi-control, ethernet for data trasmittance options.
Items | P8 Outdoor full color led display |
Pitch size | 8mm |
Module size | 256mm*128mm |
Panel pixel(dots) | 32*16 |
LED Lamp | Epistar |
Pixel configuration | 1R1G1B |
Cabinet size | 1024mm*1024mm/768mm*768mm |
Wavelength (dominant) | Red:623nm±1.5nm / Green:525nm±1.5nm / Blue:470nm±1.5nm |
Color scale | 256-65536grade/16777216colors |
Pixel density | 15625pixels/square meter |
View angle(H/V) | 120/60degree |
Brightness | ≥7000cd/sqm |
View distance | 2.5-150m |
Power consumption | 200-1200W/sqm |
Net weight | 60kg/square meter |
Operating temperature | —25℃~+60℃ |
Operating humidity | 10%—95%RH |
Life time | ≥100,000hours |
Exchange frame speed | >150frames per second |
Refresh frame frequency | 2000Hz |
Control distance | 120m (without relay),single mode fiber: |
20000m,multi mode fiber:500m-20km | |
Power | 110V/220V/380V±15% 50Hz |
operating system | Windows98/Me/2000/Xp/windows7 |
Drive mode | constant current driving |
display mode | VGA640X480—VGA1600X1024 |
Protections for outdoor display | IP65 |
Accepting signal | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
P8 Outdoor Led Display Module Parameter:
Item | Specification Parameter |
Pixel Pitch,Resolution rate,size | 8mm,40*40,320*320*34mm |
Pixel color, Pixel LED | 1R1G1B, SMD3535 |
Working voltage,Module Power | DC5V,78W |
Driving way | 1/4 |
